Type	Vrrm(KV)	If(A)	Vfm(V)	Ifsm(A)	TRR(nS)	Irrm1/Irrm2(uA)
Condition	Ta=25℃ Ir=2uA	Ta=25℃	Max	tp=8.3ms 50℃		Ta=25℃/100℃
3QLA5K2	5	2	7.5	50	100	2/20
3QLA5K5	5	5	7.5	100	100	2/20
3QLA5K10	5	10	7.5	200	100	2/20
3QLA10K2	10	2	15.0	50	100	2/20
3QLA10K5	10	5	15.0	100	100	2/20
3QLA10K8	10	8	15.0	160	100	2/20
3QLA15K2	15	2	22.5	50	100	2/20
3QLA15K5	15	5	22.5	100	100	2/20
3QLA20K2	20	2	30.0	50	100	2/20
3QLA20K3	20	3	30.0	75	100	2/20
3QLA25K1	25	1	37.5	30	100	2/20
3QLA25K2	25	2	37.5	50	100	2/20
3QLA25K3	25	3	37.5	75	100	2/20
3QLA30K1	30	1	45.0	30	100	2/20
3QLA30K2	30	2	45.0	50	100	2/20
以上数据为单臂参数
参数定制，请联系我们的客服 : sales@hvdiode.com
